Multi Arc Colorful Glass Coating Equipment Pvd Decorative Vacuum Coating Machine

Multi Arc Colorful Glass Coating Equipment Pvd Decorative Vacuum Coating Machine

Multi Arc Colorful Glass Coating Equipment Pvd Decorative Vacuum Coating Machine
Multi Arc Colorful Glass Coating Equipment Pvd Decorative Vacuum Coating Machine
Multi Arc Colorful Glass Coating Equipment Pvd Decorative Vacuum Coating Machine
Product Details:
Place of Origin: China
Brand Name: JXS
Certification: CE
Model Number: JXS-2000
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: As per configuration
Packaging Details: wooden case, plastic film
Delivery Time: 70 working days
Payment Terms: L/C, T/T
Supply Ability: 100 sets/year
Contact Now
Detailed Product Description
Chamber Material: Stainless Steel 304 Control System: Full Auto, Semi Auto, Manual
Warranty: 1 Year Structure: Vertical Front Open Or Vertical Loading
Voltage: 380V, 50Hz Or Custom Made Chamber Size: Custom Made
Pump Group: Mechanical Pump+Roots Pump+Diffusion/Turbo Pump Coating Technology: Multi Arc Or Multi Arc + Magnetron Sputtering
High Light:

Multi Arc Colorful Glass Coating Equipment

,

Pvd Decorative Glass Coating Equipment

,

Pvd Decorative Vacuum Coating Machine

Colorful Glass pvd decorative vacuum coating machine



Working principle: Cathodic arc deposition or Arc-PVD is a physical vapor deposition technique in which an electric arc is used to vaporize material from a cathode target. The vaporized material then condenses on a substrate, forming a thin film. The technique can be used to deposit metallic, ceramic, and composite films.

Multi Arc Colorful Glass Coating Equipment Pvd Decorative Vacuum Coating Machine 0



Application: door handle, door hinge, sanitary ware, tableware, cellphone accessory, stainless steel furniture, stainless steel sheet, ceramic tile, glass crystal, bags and suitcases hardware, watch, stainless steel signboard, etc.



Color: gold, silver, rose gold, blue, gray, black, rainbow.





Multi Arc Colorful Glass Coating Equipment Pvd Decorative Vacuum Coating Machine 1Multi Arc Colorful Glass Coating Equipment Pvd Decorative Vacuum Coating Machine 2





Film feature: strong adhesion, high hardness, gorgeous decorating effect.



Green process: no harmful gas, no waste water, no waste material.



Multi-Arc Coating Equipment Model
Model JXS-1010 JXS-1215 JXS-1820 JXS-2336 JXS-2345
Chamber(mm) D1000×H1000 D1200×H1500 D1800×H2000 D2300×H3600 D2300×H4500
Structure Vertical door structure, pumping system and water cooling system
Vacuum System Diffusion Pump or Molecular Pump + Hold Pump + Rough Pump + Roots Pump
Ultimate Pressure 1.0- 6.0×10-4Pa, Non-loading cooling
Temp. Normal temp- 300°C to 450°C - 600°C, controlled and adjusted(PID temp. control)
Gas Ar, N2,O2, C2H2,etc.
Cooling Water cooling circulation, industrial cooling tower or industrial water chiller(refrigerating machine) or cryogenic system.(customers provide)
Controlling Manual, semi-auto, full auto
Air Pressure 0.5-0.8MPa
Water Temp. ≤25°C
Water Pressure ≥0.2MPa
Total Power 25-65KW 65-105KW 85-115KW 95-145KW 130-180KW
Output Frequency 380V, 50Hz(Custom made)
Occupied Area 35~50m² 55~95m² 75~105m² 125~175m² 135~205m²
Remark Customization



3D Effect

Multi Arc Colorful Glass Coating Equipment Pvd Decorative Vacuum Coating Machine 3



PVD Coating Film Advantages

I)Strong Adhesion Film For Longer Using Life

II)Decoration For Higher Selling Value

III)Decorative Coating Colors For Better Viewing Feeling



Why choose JXS Vacuum?

I)Custom Made PVD Coating Machine

II)1 Year Warranty

III)7 Days Free Installation & Training

IV)On Line Or On-The-Spot After-Sales Service

V)Offer PVD Coating Machine Spare Part & Consumable



Multi Arc Colorful Glass Coating Equipment Pvd Decorative Vacuum Coating Machine 4

Foshan Jin XinSheng Equipment CO., LTD., is a vacuum coating machine manufacturers. The company is located in foshan city with beautiful environment.
Vacuum coating equipment series of the company including: multi-arc ion coating equipment, medium frequency magnetron vacuum coating equipment, vacuum evaporation plant, electronic gun coating equipment, tool special coating equipment, gold tube special coating machine, continuous coating production line etc. Various vacuum plating equipment is widely used in optics, lamp, electronic, ceramics, glass, mosaic, building materials, hardware, cutters, tools and moulds, watch, medical, automobile, spaceflight and other high-tech industries, and it has succeeds in developing coating process scheme to meet different needs for the customers. Standing in the perspective of customers, saving every bit of a drop for customers, is our goal of being a manufacturing of environmental protection equipment. Our company will do our best to provide you with the best quality vacuum coating equipment.



Packing and Shipping

Multi Arc Colorful Glass Coating Equipment Pvd Decorative Vacuum Coating Machine 5



Multi Arc Colorful Glass Coating Equipment Pvd Decorative Vacuum Coating Machine 6



FAQ

.

Q1: How about your company?
A1: We are a leading manufacturer and provider of total integrated supply chain solutions for vacuum coating machine.



Q2: How about the quality control about our products?
A2: We have the ISO9001 QMS-Quality Management System.



Q3: Do you provide after-sales service?
A3: After-sales problems shall be solved on line within 48 hours.
Long-term product solution and remote technical support is provided.



Q4: What about the payment terms?
A4: T/T and it is also flexible according to different types of machine.



Q5: About the package?
A5: Nude packing or wooden case carton container.



Q6: Do you provide the second-hand machine?
A6: Yes. We also provide second-hand machine, you can provide your requirements to our salesman.



Q7: What is lead time of PVD electro colouring system?
A7: About 60 working days.



A8: Do you teach all PVD colouring details?
A8: Yes, we will teach you in your factory.



A9: Do you have quality guarantee for PVD electro colouring system?
A9: 1 year guarantee and lifetime technical support.



A10: If we buy the machine how can we install the machine in my factory and you can't leave the country due to the COVID-19 ?
A10: We can send you the Equipment Installation Guide and instruct you to install by online video.
