One-Stop Service for PVD Vacuum Coating Machine.
From PVD vacuum coating factory building to consumable items and spare parts offering.
|Place of Origin:||China|
|Minimum Order Quantity:||1 set|
|Price:||As per configuration|
|Packaging Details:||wooden case, plastic film|
|Delivery Time:||70 working days|
|Payment Terms:||L/C, T/T|
|Supply Ability:||100 sets/year|
|Chamber Material:||Stainless Steel 304||Control System:||Full Auto, Semi Auto, Manual|
|Warranty:||1 Year||After-Sales:||Engineer Available To Service Overseas|
|Structure:||Vertical Front Open||Coating Film:||TiN, CrN, TiC, TiAlN, AlTiN, TiCN, Etc.|
|Voltage:||380V, 50Hz Or Custom Made||Chamber Size:||Custom Made|
|Pump Group:||Mechanical Pump+Roots Pump+Diffusion/Turbo Pump||Coating Technology:||Multi Arc|
diamond coating machine,
diamond like carbon coating equipment
Working Theory: Cathodic arc deposition or Arc-PVD is a physical vapor deposition technique in which an electric arc is used to vaporize material from a cathode target. The vaporized material then condenses on a substrate, forming a thin film. The technique can be used to deposit metallic, ceramic, and composite films.
Film Type: TiN, TiAlN, AlTiN, TiC, TiCN, CrN, etc.
Film Feature: Strong film adhesion, high hardness, anti-friction, long using life
Application: Cutting tools, milling cutter, mould, drill, etc.
